Single Mode OS2 LC UPC Ribbon Fiber Pigtails G657A1 4/6/8/12 Strand

Name: Single Mode OS2 LC UPC Ribbon Fiber Pigtails G657A1 46812 Strand
Brand: UNIFIBER-OEM
Price: 1 USD

China Single Mode OS2 LC UPC Ribbon Fiber Pigtails G657A1 4/6/8/12 Strand wholesale

Brand Name : UNIFIBER-OEM

Model Number : 4/6/8/12 Strand Single Mode OS2 LC/UPC Ribbon Fiber Pigtails

Certification : ROHS

Place of Origin : CHINA

MOQ : 10pcs

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 1000pcs/day

Delivery Time : 3~5 business days

Packaging Details : PE bag

Product : 4/6/8/12 Strand Single Mode OS2 LC/UPC Ribbon Fiber Pigtails

Fiber Counts : 4/6/8/12 Strand

Connector : LC/UPC or SC/APC

Length : 1.5m

Fiber Type : Single mode OS2 G657A1

Name : Ribbon Fiber Pigtails

Contact Now

4/6/8/12 Strand Single Mode OS2 Ribbon Fiber Pigtails with different connectors of SC, LC,FC, ST , with UPC or APC polish type. These can be come with singlemode, multimode or OM3, with 900um tight buffer PVC or LSZH jacket. Widely used in CATV, FTTH/FTTX, telecommunication networks, premise installations, Data processing networks, LAN/WAN network, and more.

Features

4/6/8/12 Strand avaliable

SC, LC,FC, ST connectors with UPC or APC polished

Low insertion loss, high return loss
Good in repeatability and exchangeability

Application

Data Centre
Telecommunication networks
CATV
LAN and WAN
FTTX
Broadband network

Specification

Parameter	Singlemode Fiber			Multimode Fiber
Parameter	PC	UPC	APC	PC
Insertion Loss(dB)	≤0.3	≤0.2	≤0.3	≤0.3
Return Loss(dB)	≥45	≥50	≥60	≥20
Exchangeability(dB)	≤0.2
Plug-pull life(times)	＞1000
Operating temperature(℃)	-40~+75
Storage temperature(℃)	-45~+80
Fiber model	φ0.9mm, φ2.0mm, φ3.0mm
